Float density polyethylene

Float density polyethylene

     Medium density polyethylene, high-strength polyurethane foam filled. Reasonable structure, excellent performance. Water floating material as mud tubes become traditional steel pontoon alternative.
Product Features:
     1 toughness, excellent impact resistance, especially for offshore construction.
     2 light weight, easy installation and removal, transfer of low transportation costs.
     3 abrasion resistance and long life.
     4 low price, cost significantly better than steel pontoons.
Note:
     1 floating body 2 is a group (a two-piece composition) may lose mud float tube 6 Mega hose 1.5 m;
     2 OD 4 m X length 4 meters below the variety of the floating body can produce.
Main Specifications Sheet floating body

Project	Shell performance indicators	Project	Internal performance indicators
Tensile strength	≥13.1MPa	Water absorption	1-2g/100cm2
Elongation	≥11.1%	Breaking strength	0.08-0.1MPa
Impact strength	≥32.1KJ/m2	Elongation	4-6%
Bending Strength	≥15.7MPa	Compressive strength	0.1-0.24MPa



Ship	Lose soil pipe inside diameter	Outside diameter of the floating body	Floating body diameter	Floating body length
200m3/H	Φ400-420	Φ1310	Φ430	1335
350m3/H	Φ550-560	Φ1300	Φ576	1400
Beaver1600	Φ500	Φ1370	Φ522	1400
Beaver3800	Φ650	Φ1500	Φ680	1800
Beaver4600	Φ700	Φ1530	Φ730	1840
8000绞	Φ800	Φ1780	Φ840	2000
5000m3/H	Φ900	Φ2100	Φ950	2300
